| Parameter Table of Tubular Twisting Machine |
| Serial numberNO. | Device model Type | Unwinding wire diameter Inlet Wire Diameter | Main power Main Power | Main speed Main Rotating Speed | |
| The smallest Min. | maximum Max. | Kw | r/min | ||
| 1 | 6/200 | 0.20 | 0.75 | 15 | 2200 |
| 12/200 | 0.20 | 0.75 | 18.5 | 2000 | |
| 18/200 | 0.20 | 0.75 | 22 | 1800 | |
| 36/200 | 0.20 | 0.75 | 37 | 1400 | |
| 2 | 6/300 | 0.40 | 1.40 | 22 | 1600 |
| 12/300 | 0.40 | 1.40 | 30 | 1400 | |
| 18/300 | 0.40 | 1.40 | 37 | 1100 | |
| 36/300 | 0.40 | 1.10 | 45 | 650 | |
| 3 | 6/400 | 0.60 | 2.50 | 30 | 900 |
| 18/400 | 0.6 | 2.5 | 45 | 800 | |
| 36/400 | 0.60 | 2.50 | 90 | 750 | |
| 4 | 6/500 | 1 | 3.5 | 37/45 | 750 |
| 12/500 | 1.20 | 3.50 | 45 | 700 | |
| 18/500 | 1.20 | 3.5 | 55 | 650 | |
| 36/500 | 1.2 | 3.5 | 75 | 550 | |
| 5 | 6/630 | 1.4 | 5.5 | 55 | 600 |
| 18/630 | 1.4 | 5.5 | 90 | 450 | |
| 6 | 6/760 | 2.00 | 6.00 | 90 | 400 |
| 8/760 | 2.00 | 6.00 | 90 | 400 | |
| 7 | 6/800 | 2.00 | 7.00 | 90 | 350 |
| 8/800 | 2.00 | 7.00 | 90 | 350 | |
| 8 | 6/1000 | 3.00 | 12.00 | 110 | 320 |
| 8/1000 | 3.00 | 12.00 | 110 | 320 | |
