Product Description
Description of Fully Automatic Straight Wire Drawing Machine For Making Steel Wires In High.
The straight wire drawing machine series of our company have absorbed the advanced advantages from both at home and broad in the machinery design process. Our machine have all kinds of design and configurations according to the different finished products and different request from clients, which makes us in the leading position of concerning the product characterisitics for user. It is applicable to drawing spring steel wires, tyre rib steel wires, steel wires for ropes, optical fiber steel wires, CO2 shield welding wires, flux cored electrodes for air welding, alloy and stainless steel wires, aluminum clad wires, under-relaxation pre-stressed steel wires and so on.

Advantage of this equipment is low noise, stable transmission, high output efficiency, easy operation and maintenance. Machine frame and box body of this machine is welded by good steel plage and steel channel, compact structure and good strength.

We could supply the whole drawing machine line. The Composing of production line:

Horizontal rotating Pay-off(including wire push device) → Surface Pre-treatment device → Straight wire drawing machine → coiler take up

Instruction of wire drawing machine

Transportation system:

he transmission way of the wire drawing machine is AC frequency conversion motor + linkage narrow V belts+ gearbox with hard gear

surface.Special structure type gearbox is adopted to ensure the reliability under high speed running and good shock absorption and heat

dissipation effect of gearbox. The bearings of gearbox with hard gear surface adopt Japanese brand NSK, the oil seals adopt products from Germany CFW to ensure the reliability and advantage of gearbox.

Way of speed adjusting:
AC Frequency conversion speed adjusting or DC speed adjusting.

Way of control:
Profibus field bus control system, touching screen show, human-computer communication, long-distance
diagnose function.

Way of take-up:
Spooler take-up, trunk take-up, headstand take-up, and all can take-up wire without stop work.

Way of pay-off:
Spooler pay-off, high pay-off frame, "-" type pay-off, duck-nip pay-off, can pay-off without stop work.

Main function:
Slowdown to stop at fixed length automatically, wire broken test and stop work automatically, cut off any block to compose new technical process freely,slowdown to stop automatically when the protecting shield is open, show of all kinds of fault information and the solution, inspection and control of all kinds of running information.

Material that can be drawn:
Steel wire (High, middle, low carbon steel wire, stainless steel wire, pre-tension steel wire, bead wire, rubber tube wire, spring steel wire, cord wire and so on).Welding wire (Air protecting welding wire, submerged arc welding wire, flux cored wire and so on).lectric wire and cable (Aluminum-clad steel wire, copper wire, aluminum wire and so on).Alloy wire and other kinds of metal wire.
Notes: All the parameters might be changed according to the actual situation.


Technical parameter
